power cable

3 Core Rubber Submersible Flate Cable

our company is honored to provide varaity of copper cables and wires .making quality and diverse products and strong communication with domestic and foreign customers is one of the duties of this company.The constant pursuit of elevation the level of knowledge ,skills and the participation of the human capital within the organization ,optimal utilization of machinery and equipment ,diversification of product offfering ,and increasing efficiency through the optimal use of resources are integral parts of the company’s quality policies.This principles serve as the guiding principles for all activities of the company

Groundwater wells are drilled and water is supplied with PVC pipes, groundwater pumping systems are powered by electricity to solve drought problems



Categories

Cable Standard

DIN VDE 0281 part 810,
IEC 245 & BS 6007, BS 6899

Conductor : Bare Burch Copper S:8130
Insulation : PVC As Per IS:5831
Outer Sheath: PVC As Per IS:5831

Standard Packing

Coils 100, 200, 300, 500, 1000 m

Silent Features

Application

Ideal for irrigation Pumps, Drinking Water Supply Pumps, Submersible Pump Motor Power Supply

Technical Data

Operating Temp : 10° C to max =90°C
Nominal Voltage : 1.1 KV
Test Voltage : 3.0 KV
Min. Bending Radius: 6 x cable diameter

Core Colur

As Per IEC:60227 – Black, Light Blue, Brown As Per IS:694:2010 – Red, Yellow, Blue
